How to change chart appearance using a theme

If a developer provides a theme to apply to a chart, the library file that contains the theme typically resides in the Resources folder in an Encyclopedia volume, for example:

/Resources/ThemesReportItems.rptlibrary

To apply a theme to a chart, complete the following tasks:

1	Using Data Analyzer, view a chart.

2	Choose Theme.

3	In Theme, choose a theme name. For example, choose Chart Gray, as shown in Figure 6-36.

Figure 6-36

Choosing ThemesReportItems.Chart Gray theme

The theme applies to the chart. This Chart Gray theme displays light yellow and blue columns on a gray background color, as shown in Figure 6-37.

Figure 6-37

Viewing a chart with the applied theme
